Spring-cage terminal
TCT2.5-2-PE
Connection method:Spring-cage connection,IEC Rated Voltage:500V,Number of connections:6,Number of levels：3,Cross section:28-12AWG
Parameters
-
SUPU ID
TCT2.5-2-PE -
Width
5.2mm -
Number of levels
3 -
Number of connections
6 -
Connection method
Spring-cage connection -
Protection Level
IP20 -
Insulation material
PA66
-
Insulation material group
Ⅰ
-
Contact material
Copper alloy
-
Contact plating
Sn,Plated
-
Ambient temperature (operation)
-40℃～105℃
-
Ambient temperature (assembly)
-5℃～70℃
-
Ambient temperature (storage)
-25℃～60℃
-
Permissible humidity (storage/transport)
30%～70%
Commercial data
-
Order No
TCT2.5-2-PE
