IP67 connector
ESF-RS100A16BB1
Connectors suitable for energy storage modules:
Color: Black
Wire cross-section: 16mm²
Rated voltage: 1500V DC
Rated current: 100A
Connection method: screw
Contact type: Pin
Parameters
-
SUPU ID
ESF-RS100A16BB1 -
Number of connections
1 -
Connection method
Screw thread -
Protection Level
IP67 -
Operating temperature range
-40℃～125℃ -
Insulation material
PA
-
Insulation material group
Ⅲ
-
Contact material
Copper alloy
-
Contact plating
Ag,Plated
-
Insertion/withdrawal cycles
100
-
Insertion force
≤75N
-
Withdrawal force
≥10N
Technical data
-
IEC Rated Current
100A -
IEC Rated Voltage
1500V -
Overvoltage category
Ⅲ
-
Degree of pollution
3
-
Rated impulse voltage
12.3KV -
Stripping length
/ -
Rated cross section(AWG)
16mm²（ AWG6）
-
External cable diameter
/
Commercial data
-
Order No
ESF-RS100A16BB1 -
Packing unit
1 -
Minimum order quantity
PCS -
Weight per unit (without packaging)
0.74KG -
Single piece weight
0.7KG
