Terminal block
XF4-20C
Power Module，Flexible，20P，10V+/10V-，Terminal Block Connection，No LED，DIN 35 rail mounting（H/V）
Parameters
-
SUPU ID
XF4-20C -
Number of connections
20 -
Protection Level
IP20 -
Operating temperature range
-25~+70℃ -
Mounting Type
DIN 35 rail mounting
Technical data
-
IEC Rated Current
10A -
IEC Rated Voltage
250VAC/DC -
Overvoltage category
Ⅱ
-
Degree of pollution
2
-
Stripping length
8-10mm -
Cable cross section (AWG)
500VAC 1min
-
Insulation Resistance
500MΩ/500VDC
-
Wire Range
24-16AWG
Commercial data
-
Order No
XF4-20C -
Packing unit
PCS -
Minimum order quantity
30 -
Single piece weight
24g
Authentication
