Terminal block
X2-A16R-LU
50mm ordinary base, Horn connector input, MC-RJ in-line Terminal 16 outputs, with LED indicator, high and low level switching input
Parameters
-
SUPU ID
X2-A16R-LU -
Number of connections
16 -
Protection Level
IP20 -
Operating temperature range
-20℃-+70℃ -
Mounting Type
35mm DIN/螺钉安装
Technical data
-
Overvoltage category
Ⅱ
-
Degree of pollution
2
-
Stripping length
9-10mm -
Cable cross section (AWG)
500VAC/1min
-
Insulation Resistance
500MΩ
-
Wire Range
28-16AWG
-
Coil Current
/
-
Load Current
1A
-
Coil Voltage
/
Commercial data
-
Order No
X2-A16R-LU -
Packing unit
PCS -
Minimum order quantity
5
Authentication
