Relay module
X1S-20PP-1AU
50mm base small relay, 20 MC-DTP/TP terminal input and output, 1 set of normally open contacts, high and low level switching input.
Parameters
-
SUPU ID
X1S-20PP-1AU -
Number of connections
20 -
Protection Level
IP20 -
Operating temperature range
-20℃-+70℃ -
Mounting Type
DIN rail mounting/screw mounting
Technical data
-
Overvoltage category
Ⅱ
-
Degree of pollution
2
-
Stripping length
9-10mm -
Cable cross section (AWG)
500VAC/1min
-
Insulation Resistance
500MΩ
-
Wire Range
28-16AWG
-
Coil Current
4.6mA
-
Load Current
5A
-
Coil Voltage
24V DC
Commercial data
-
Order No
X1S-20PP-1AU -
Packing unit
PCS -
Minimum order quantity
5
