Parameters
-
SUPU ID
TC1.5-3-GY -
Width
4.2mm -
Pitch
3.5
-
Number of levels
1 -
Number of connections
2 -
Connection method
直插弹簧接线 -
Protection Level
IP20 -
Operating temperature range
-40~+105 -
Insulation material
PA66
-
Insulation material group
4
-
Contact material
Copper alloy
-
Contact plating
Sn,Plated
Technical data
-
IEC Rated Current
8 -
IEC Rated Voltage
500V -
Overvoltage category
Ⅲ
-
Degree of pollution
3
-
Rated impulse voltage
6KV -
Conductor cross section rigid
0.2-1.5mm² -
Conductor cross section flexible
0.2-1.5mm² -
Conductor cross section flexible,with furrule
0.2-1.5mm² -
Stripping length
8-10mm
Commercial data
-
Order No
3040054 -
Packing unit
600 -
Minimum order quantity
1200 -
Weight per unit (without packaging)
10g -
Single piece weight
9.89g
Authentication
