Barrier terminal
TBR100-XXC-LR-001
pitch：25.0mm，rated voltage UL600V, rated current UL101A, color: black, Rated cross section 20-2AWG
Parameters
-
SUPU ID
TBR100-01C-LR-001 -
Pitch
25.0 -
Number of levels
Single layer -
Number of connections
XX -
Connection method
Screw connection -
Protection Level
IP20 -
Operating temperature range
-40°C ~+125°C -
Insulation material
PC
-
Insulation material group
Ⅲ
-
Contact material
Copper alloy
-
Contact plating
Sn plated
Commercial data
-
Order No
TBR100-01C-LR-001
