Barrier terminal
TB-B6-9.52HXXC-50-001
pitch：9.52mm，rated voltage IEC630V, rated current IEC32A, color: black, Rated cross section 22-12AWG
Parameters
-
SUPU ID
TB/B6-9.52H02C-50-001 -
Pitch
9.52 -
Number of levels
Single layer -
Number of connections
XX -
Connection method
Screw connection -
Protection Level
IP20 -
Operating temperature range
-40°C ~+105°C -
Insulation material
PA66
-
Insulation material group
Ⅰ
-
Contact material
Copper alloy
-
Contact plating
Sn plated
Commercial data
-
Order No
TB/B6-9.52H02C-50-001
