Fixed terminal
MC-TX5.08VXXP-0001
Pitch:5.08mm
Rated Voltage：320V
Rated Current:10A
Connection method：Push-in spring connection
colour：customizable
Color
Parameters
-
SUPU ID
MC-TX5.08VXXP-0001 -
Pitch
5.08 -
Number of levels
Single layer -
Number of connections
XX -
Connection method
Push in spring connection -
Protection Level
IP20 -
Operating temperature range
-40~+105℃ -
Insulation material
PA66
-
Insulation material group
Ⅰ
-
Contact material
Copper alloy
-
Contact plating
Sn,Plated
-
Color
Green/Black/Blue/Grey/Orange/Red
Technical data
-
IEC Rated Current
10A -
IEC Rated Voltage
320V -
Overvoltage category
Ⅲ/Ⅲ/Ⅱ
-
Degree of pollution
3 2 2
-
Rated impulse voltage
4.0KV 4.0KV 4.0KV -
UL Rated Current
10A – 10A
-
UL Rated Voltage
300V – 300V
-
Conductor cross section rigid
0.2~1.5mm² -
Conductor cross section flexible
0.2~1.5mm² -
Conductor cross section flexible,with furrule
0.2~1.0mm² -
Locking screw Specification
–
-
Locking screw torque
–
-
Fixed Screw Specification
–
-
Stripping length
9-10mm
Commercial data
-
Order No
MC-TX5.08VXXP-0001
Authentication
