Plug-in terminal-Socket
MC-PA2.5H17-0002
Pitch:2.5mm
Rated Voltage：160V
Rated Current:4A
colour：customizable
Color
Parameters
-
SUPU ID
MC-PA2.5H17-0002 -
Pitch
2.5 -
Number of connections
17 -
Connection method
– -
Protection Level
IP20 -
Operating temperature range
-40~+105℃ -
Insulation material
PA66
-
Insulation material group
Ⅰ
-
Contact material
Copper alloy
-
Contact plating
Sn,Plated
-
Color
Green/Black/Blue/Grey/Orange/Red
Technical data
-
IEC Rated Current
160V -
IEC Rated Voltage
4A -
Overvoltage category
Ⅲ Ⅲ Ⅱ
-
Degree of pollution
3 2 2
-
Rated impulse voltage
1.5KV 2.5KV 2.5KV -
UL Rated Current
4A – –
-
UL Rated Voltage
125V – –
-
Conductor cross section rigid
– -
Conductor cross section flexible
– -
Conductor cross section flexible,with furrule
– -
Locking screw Specification
–
-
Locking screw torque
–
-
Fixed Screw Specification
–
-
Stripping length
– -
Use group
B/C/D
Commercial data
-
Order No
MC-PA2.5H17-0002
Authentication
