7/8 circular connector
M7-8U05C-MMSST-UC001BH
7/8, 5 pole male straight connector, unshielded, with 1 meter PVC cable
Parameters
-
SUPU ID
M7/8 -
Number of connections
5 -
Protection Level
IP67 -
Thread type
7/8-16 UN-2A -
Category
Male
-
Coding
/
-
Connection method
Moulded Type
-
Shielded
NO
-
Mechanical endurance
≥100
-
Standards
/
Technical data
-
IEC Rated Current
9A -
IEC Rated Voltage
300V DC -
Insulation Resistance
≥100MΩ
-
Contact resistance
＜10mΩ
-
Contact/surface material
CuSn/Ni/Au
-
Contact carrier material
TPU
-
Screw/nut material
CuZn
-
Sealing material
NBR
-
Cable length
1
-
Outer sheath, material
PVC
-
External sheath, color
Black
Commercial data
-
Order No
M7/8U05C-MMSST-UC001BH -
Packing unit
PCS -
Minimum order quantity
1
Authentication
