IP20 connector
ESF-SU250A19Y
Nominal operating voltage 1500V DC,Rated current 250A,Color:Orange,wiring method: screw
Parameters
-
SUPU ID
ESF-SU250A19Y -
Connection method
Screw thread -
Protection Level
IP20 -
Operating temperature range
-40℃～125℃ -
Insulation material
PA
-
Insulation material group
Ⅲ
-
Contact material
Copper alloy
-
Contact plating
Ni,Plated
Technical data
-
Overvoltage category
Ⅲ
-
Degree of pollution
3
-
Rated impulse voltage
10KV -
UL Rated Current
250A
-
UL Rated Voltage
1500V
-
Conductor cross section rigid
70mm²（ AWG2/0） -
Conductor cross section flexible
70mm²（ AWG2/0） -
Rated cross section
70mm²（ AWG2/0）
-
Can connect copper bar specifications
18*4mm and more
Commercial data
-
Order No
ESF-SU250A19Y -
Packing unit
PCS -
Minimum order quantity
1
Authentication
