IP67 connector
ESF-RS300A95YP4
Connectors suitable for energy storage modules
Color: Orange
Rated voltage: 1500V DC
Rated current: 300A
Connection method: Nuts
Contact type: Pin
wire cross-section: 95mm²
cable outer diameter: 15.2mm to 17.7mm
Parameters
-
SUPU ID
ESF-RS300A95YP4 -
Number of connections
1 -
Connection method
Bolt connection -
Protection Level
IP 67 -
Operating temperature range
-40℃~+125℃ -
Insulation material
Ⅲ
-
Insulation material group
Ⅲ
-
Contact material
Copper alloy
-
Contact plating
Ag,Plated
-
Insertion/withdrawal cycles
100
-
Insertion force
≤75N
-
Withdrawal force
≥10N
Technical data
-
IEC Rated Current
300A -
IEC Rated Voltage
1500V DC -
Overvoltage category
Ⅲ
-
Degree of pollution
3
-
Rated impulse voltage
12.3KV -
Stripping length
20±1mm -
Rated cross section(AWG)
3/0 AWG
-
External cable diameter
15.2mm~17.7mm
Commercial data
-
Order No
ESF-RS300A95YP4 -
Packing unit
Pcs -
Minimum order quantity
1 -
Single piece weight
93g
