Parameters
-
SUPU ID
ESF-RS200A50YB2-BS -
Number of connections
1 -
Connection method
Screw thread -
Protection Level
IP67 -
Operating temperature range
-40℃～125℃ -
Insulation material
PA
-
Insulation material group
Ⅲ
-
Contact material
Copper alloy
-
Contact plating
Ag,Plated
-
Insertion/withdrawal cycles
100
-
Insertion force
≤75N
-
Withdrawal force
≥10N
Technical data
-
IEC Rated Current
200A -
IEC Rated Voltage
1500V -
Overvoltage category
Ⅲ
-
Degree of pollution
3
-
Rated impulse voltage
12.3KV -
UL Rated Current
50mm²（ AWG1/0）
-
UL Rated Voltage
Positive
-
Stripping length
/ -
Rated cross section
50mm²（ AWG1/0）
-
Rated cross section(AWG)
50mm²（ AWG1/0） 35mm²（ AWG2）
-
External cable diameter
/
Commercial data
-
Order No
ESF-RS200A50YB2-BS -
Packing unit
1 -
Minimum order quantity
PCS -
Weight per unit (without packaging)
0.047KG -
Single piece weight
0.045KG
Authentication
