SUPU ID
ESF-PS200A50Y-B
Number of connections
1
Connection method
Crimp
Protection Level
IP67
Operating temperature range
-40℃～125℃
IEC Rated Current
150A
IEC Rated Voltage
1500V
Rated impulse voltage
12.3KV
Stripping length
20mm±1mm
Order No
ESF-PS200A50Y-B
Packing unit
1
Minimum order quantity
PCS
Weight per unit (without packaging)
0.064KG
Single piece weight
0.062KG
