Crimp terminal
BP635V3XF-WT-0000
Pitch:6.35mm
Rated Voltage：600V
3 row, 2column
CE
Color
Parameters
-
SUPU ID
BP635V32F-WT-0000 -
Pitch
6.35 -
Number of levels
Multi-Layer -
Number of connections
X -
Connection method
Cold Pressure Wiring -
Protection Level
IP20 -
Operating temperature range
-40~+105℃ -
Insulation material
PA66
-
Insulation material group
Ⅰ
-
Contact material
–
-
Contact plating
–
-
Color
White
Commercial data
-
Order No
BP635V32F-WT-0000
Authentication
