Spring-cage terminal
210927
Connection method:Spring-cage connection,IEC Rated Voltage:800V,Number of connections:2,Number of levels：1,Cross section:28-8AWG
Parameters
-
SUPU ID
210927 -
Width
10mm -
Number of levels
1 -
Number of connections
2 -
Connection method
Spring-cage connection -
Protection Level
IP20 -
Insulation material
PA66
-
Insulation material group
Ⅰ
-
Contact material
Copper alloy
-
Contact plating
Sn,Plated
-
Ambient temperature (operation)
-40℃～105℃
-
Ambient temperature (assembly)
-5℃～70℃
-
Ambient temperature (storage)
-25℃～60℃
-
Permissible humidity (storage/transport)
30%～70%
Commercial data
-
Order No
210927
Authentication
